The WM1000 industrial sawmill is designed to saw large logs up to 1.7 metres in diameter. Durable and easy to use, this sawmill features a saw head with a massive throat opening that moves along a twin-rail frame.
The Wood-Mizer WM1000 saws large softwood, hardwood and tropical logs up to 1.7 metres in diameter. This sawmill uses narrowband, thin-kerf blades to deliver higher log yields than traditional large-log sawing methods.
Heavy-duty, accurate, and easy-to-use, the WM1000 features a massive cutting head that moves along a twin-rail frame to convert large logs into halves, quarters, finished boards, or cants for resawing. The operator controls all cutting functions while standing on a platform that moves with the head and includes electronic setworks for accurate cutting.
The WM1000 uses thin-kerf, narrow band blades that are 50 mm (2") to 75 mm (3") wide, resulting in significantly improved log yield and less wood waste.
Built to last and run effortlessly in industrial applications, it easily integrates into existing operations with low installation costs. Simply extend the rails to cut longer logs.
The standard setworks increases productivity and accurately positions the head for the next cut.
A log of 1.7 m (67") diameter can be cut in the centre or sawn through and through with the log on the ground.
The standard setworks increases productivity and accurately positions the head for the next cut.
The use of double-carrying blocks reduces vibration and ensures proper support of the blade while cutting.
The hydraulic system ensures constant tension during the cutting process.
| Power Selections | |
|---|---|
| Power Selections | 22kW (30HP) electric 30kW (40HP) electric 37kW (50HP) electric |
| Cutting Capacities | |
| Max Width of Cut | 170cm (67'") |
| Max Log Length | unlimited, based on rail length |
| Max Depth of Cut | 99cm (39") |
| Min Log Diameter | 30cm (12") |
| Blade | |
| Blade Length | 9,800mm (386") |
| Blade Guides Style | Double Block Guides |
| Blade Lubrication System | Two-sided Blade Lubrication |
| Blade Tension System | Hydraulic Tension System |
| Blade Wheel Diameter | 1070mm (42") |
| Blade Wheel Type | Crowned Steel Wheels |
| Blade Width | 50mm (2") 75mm (3") |
| Head Features & Options | |
| Blade Guide Arm | Adjusted with Control Switch |
| Blade Engagement | On/Off Button (Electric Versions) |
| Head Up/Down | Electric Up/Down |
| Head Forward/Reverse | Variable Speed Power Feed |
| Setworks | SW Setworks |
| Operator Location | Ride Along Control Station |
| Bed Features & Log Handling | |
| Bed Rails | 10 m Rails (Set of 2) |
| Additional Bed Options | 5 m Rails Extensions (Set of 2) |
| Machine Dimensions & Requirements | |
| Delivery Methods | Container or truck |
| Bed Construction | Twin Rail |
| Safety Standards | CE |
| Electrical Requirements | 400V 50Hz 3Ph |
